SMSL SH-8 Balanced Headphone Amplifier

Upgrade AfterDark. Clementine Power Cable

S.M.S.L. SH-8 Balanced Headphone Amplifier

  • Innovated designed with all discrete output stage circuit, which has ultra low distortion, as low as 0.001%, and the output current for amplification.
  • A fully balanced circuit design from inputs to outputs.
  • Use electronic volume control to ensure the volume level are the same for left and right channel.
  • Audio grade component and HIFI coupling capacitors.
  • Protection with mute circuit and protection circuit, for headphones.
  • Built-in tone control function and SDB EQ mode, easily adapt your headphones.
  • Powered by a linear power supply, the all-aluminum CNC milling chassis to reduce magnetic noise.
  • The OLED display and user-friendly operating system are easy to understand and  can be operated by remote controller of SU-8.

Specification:

Input interface:Unbalanced (RCA) x 1, Balanced (XLR) x 1

Output interface :6.35mm headphone jack, balanced headphone jack

Unbalanced headphones
32Ω 420mW
64Ω 377mW
150Ω 190mW
300Ω 100mW
600Ω 51mW
THD+N:0.0009%
SNR :107dB

Balanced headphones
32Ω 655mW
64Ω 835mW
150Ω 717mW
300Ω 400mW
600Ω 205mW
THD+N:0.001%
SNR :109dB

Power Consumption :3.5W
Standby power<0.1W
Size :185x40x125 (WxHxD)
Weight :1.0kg

所有發燒產品從設計,生產和裝配及售後服務將會在香港每日夜晚9點開始...人手製作。
因為店主只能在晚上開始生產線,店主每晚只能生產有限的AfterDark.產品。

所有客戶現在可以通過訪問online shop下訂單,  並通過Visa卡 / Master卡/ PayPal/ Apple Pay/ Goggle Pay 在線直接付款, 接受一切國際訂單。AfterDark網上商店.



Type: DAC
